Please Contact Us to Order to offer best price and delivery time for Josef Emmerich - SP528S Piston Diaphragm Pump type number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Josef Emmerich - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy SP528S by Josef Emmerich in United States?
You can purchase SP528S by Josef Emmerich from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the SP528S?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Josef Emmerich in United States?
While we are not the official distributor or seller of Josef Emmerich in United States, we source our products from reliable channels and offer you original Josef Emmerich equipment at competitive prices.
How can I access SP528S catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for SP528S on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for SP528S?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Josef Emmerich |
| Product | SP528S |
| Description | Piston Diaphragm Pump type |
| Internal code | ONR388454 |
| Weight | 1135 |
| Custom code | 84135080 |
| Technical specification | Design: double-acting as horizontal one-cylinder pump with vertical diaphragm casing Capacity (m³/h) : 20 ... 0, variation automatically, for filterpress feeding Head (bar) : 16 Piston-diameter (mm) : 175 Piston stroke (mm) : 125 Stroke rating (min-1) : 66 Type of valve : ball valve with inspection opening and changeable valve seat Valve DN : 80 Average velocity within valve (m/s) : 1,34 at the capacity of 20 m³/h Design of Pump Head : Diaphragm Boxes with separate Diaphragm Box Covers for easy inspection and exchange of the diaphragms, without the necessity to dismantle any pipes and fittings or others Material of parts that come into contact with the Liquid/Slurry to be handled are made of; please check the quoted materials. Pump body and valves : Cast iron Pulsation dampener : Steel, P235GH (St 37-2) Diaphragm : Double diaphragm, designed as big size disc-diaphragm with internal leakage indicator Diaphragm : NBR / Perbunan, Ø 400 mm Valve-seat: Vulkollan (Polyurethane) Valve-ball: Vulkollan (Polyurethane) with steel core, Ø 115 mm Valve cage: Weight of pump (kg) : ca. 1135 Pump including: Discharge pulsation dampener Suction pulsation dampener Automatic Pressure Valve (automatically capacity regulation depending on the pressure to feed the Filter Press) Visual Leakage Indicator for pump diaphragm V-belts, V-belt pulley of pump gear, V-belt guard Electrical pressure switch (power 24 volt, DC, other voltage on demand) Drawing: 12 34 01 16 Painting : - Pre-Treatment : Sandblasting, DIN EN ISO 12944-4, SA 2,5, purificated - Priming : Rustprimer (based on artificial resin) - Finish-coat : Artificial resin coat, colour : RAL 7015, slate grey - Total thickness of coat : > 50 μm Special painting on customer’s demand EK-A2-1252,2 2 Pcs. Double diaphragm FCA (disc diaphragm) Ø 400mm, Perbunan (NBR) Weight net per unit [kg]: 1,575 Customs tariff no.:40169997 Country of origin: DE 12348701 4 pcs Valve seat FCA DN80, Vulkollan (PUR) Weight net per unit [kg]: 0,732 Customs tariff no.:84139100 Country of origin: DE 861101 4pcs Valve ball Ø 115 mm, Polyurethane FCA Ø 115 mm, PUR with steel core Weight net per unit [kg]: 3,200 Customs tariff no.:84139100 Country of origin: DE 130003,5 1 pcs Gear oil FCA Charge amount 5 liter Weight net per unit [kg]: 46,000 Customs tariff no.: Country of origin: QU (without Origin) 390201 1pcs Muzin FCA for the production of hydraulic fluid with water 1 Liter concentrate Weight net per unit [kg]: 1,000 Customs tariff no.:27101999 Country of origin: DE |
