Please Contact Us to Order to offer best price and delivery time for Huba Control - 402.9110021 Relative and differential pressure transmitter number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Huba Control - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy 402.9110021 by Huba Control in United States?
You can purchase 402.9110021 by Huba Control from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 402.9110021?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Huba Control in United States?
While we are not the official distributor or seller of Huba Control in United States, we source our products from reliable channels and offer you original Huba Control equipment at competitive prices.
How can I access 402.9110021 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 402.9110021 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 402.9110021?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Huba Control |
| Product | 402.9110021 |
| Description | Relative and differential pressure transmitter |
| Internal code | ONR4730913 |
| Weight | 0.027 |
| Technical specification | Pressure range Relative and differential 0 ... 3 – 50 mbar Operating conditions Medium Air and neutral gases Temperature Medium / ambient 0 ... +70 ºC Storage -30 ... +70 ºC Tolerable overload 100 mbar Rupture pressure at room temperature 200 mbar at 70 ºC 150 mbar Materials in contact with the medium Case construction Polycarbonate (PC) / Polyamide (PA) Diaphragm Silicone Sensor Ceramic Al2O3 (96%) Electrical overview Output 0.5 ... 4.5 V Power supply 10.2 ... 33.0 VDC Load > 15 kOhm (to GND) Current consumption < 8 mA Polarity reversal protection Connector and pcb version mechanically protected Electromagnetic compatibility The product is designed exclusively for installation in equipment. The customer is responsible for CE conformity. Dynamic response Response time < 10 ms Load cycle < 10 Hz Protection standard IP 00 Electrical connections Solderable pin in circuit board 3 pole onnector RAST 2.5 Adapter plate Mounted and soldered Pressure connection Pipe Ø 6.2 mm Mounting instruction Installation arrangement Diaphragm vertical Presssure connections facing downward Diapgragm horizontal Pressure connection P1 upwards Mounting Snap fitting 1) Adapter Mounting bracket |
