Please Contact Us to Order to offer best price and delivery time for Wika - 14325569 Differential pressure gauge number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Wika - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy 14325569 by Wika in United States?
You can purchase 14325569 by Wika from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 14325569?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Wika in United States?
While we are not the official distributor or seller of Wika in United States, we source our products from reliable channels and offer you original Wika equipment at competitive prices.
How can I access 14325569 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 14325569 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 14325569?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Wika |
| Product | 14325569 |
| Description | Differential pressure gauge |
| Internal code | ONR4021983 |
| Technical specification | Model DPGS40 Nominal size Differential pressure indication: Ø 100 mm Working pressure indication: Ø 22 mm Accuracy Differential pressure indication: ≤ 2.5 % of span (option ≤ 1.6 %) Working pressure indication: ≤ 4 % of span Scale ranges (EN 837) Differential pressure: 0 ... 0.25 to 0 ... 10 bar Working pressure: 0 ... 25 bar Max. working pressure (stat.) 25 bar Overpressure safety Either side max. 25 bar Permissible temperature Ambient: -10 ... +70 °C Medium: -10 ... +90 °C Storage: -40 ... +70 °C Ingress protection IP65 per IEC/EN 60529 Media chamber (wetted) Aluminium, EN AC–Al Si9Cu3(Fe), black lacquered (option: Stainless steel 1.4571) Process connections (wetted) 2 x G 1/4 female, lower mount, in-line, centre distance 26 mm Pressure elements (wetted) Differential pressure: Compression springs from stainless steel 1.4310 and separating diaphragm from FPM/FKM (option: NBR) Working pressure: Bourdon tube from Cu-alloy Transmission parts (wetted) Stainless steel 1.4301, 1.4305, 1.4310, FPM/FKM (option: NBR) Sealings (wetted) FPM/FKM (option: NBR) Movement Copper alloy Dial Differential and working pressure indication: White dial, black lettering Pointer Differential and working pressure indication: Blue pointer Zero adjustment for differential pressure indication Via screw in the dial Case Aluminium, EN AC–Al Si9Cu3(Fe), black lacquered Window Plastic, with plug screw for zero and switch point adjustment Weight approx. 1.4 kg |
